Late glacial and Holocene Ostracoda from the Melilla cold-water coral mound field

Abstract

The ostracod assemblages from sediment core TTR17-401G recovered from the Melilla cold-water coral mound field in the eastern Alboran Sea spanning the last 13 ka are analysed quantitatively, taxonomically and palaeoecologically. The core can be subdivided in three distinct assemblages linked to environmental shifts during the Younger Dryas and the Bølling–Allerød interstadial. A total of 9 ostracod species is recorded, Paracypris polita is dominant throughout the core. Common accessory taxa Cytherella robusta, Echinocythereis vidua and Macromckenziea ligustica characterize the well-oxygenated ostracod assemblage 2 affected by the Younger Dryas. Favourable growth conditions for ostracods during the latter are indicated by large-sized Krithe praetexta specimens.

1 Introduction

The Alboran Sea as the westernmost part of the Mediterranean Sea is delimited by the lines Cape Trafalgar-Cape Spartel in the west and Cape de Gata-Cape Fegalo in the east that represents an approximately 400 km long and 200 km wide basin with water depths reaching about 1500 m (Fig. 1) (GEBCO https://www.gebco.net/data_and_products/gridded_bathymetry_data/; IHO 1953). The Alboran Sea consists of several subbasins with the prominent Alboran Ridge separating the West Alboran Basin from the South Alboran Basins (Comas et al. 1999). The Melilla CWC mound field (MMF) is located southeast of the Cape Tres Forcas on a platform bordering the South Alboran Basin to the south.

Fig. 1

Bathymetry of the Alboran Sea, simplified large-scale hydrology and location of core TTR17-401G (AJ Atlantic jet, AR Alboran ridge, DMW deep Mediterranean water, EAB eastern Alboran Basin, EAG eastern Alboran/anticyclonic gyre, LIW Levantine intermediate water, SAB southern Alboran Basin, WAB western Alboran Basin, WAG western Alboran/anticyclonic gyre; based on GEBCO https://www.gebco.net/data_and_products/gridded_bathymetry_data/, Millot 1987, Viúdez et al. 1998, Comas et al. 1999, Renault et al. 2012, Stalder et al. 2015)

The submarine morphology of the MMF is characterized by up to 100 m high biogenic carbonate buildups with a diameter ranging up to 476 m that cover a surface of about 100 km² in water depths ranging from 250 to 600 m (e.g. Fink et al. 2013).

Hydrologic exchange of three predominant water masses between the Atlantic Ocean and the Mediterranean Sea characterize the modern Alboran Sea. Modified Atlantic Water enters the Strait of Gibraltar in the uppermost water column as so-called Atlantic Jet (Fig. 1; Prieur and Sournia 1994; Viúdez et al. 1998; Renault et al. 2012), driving two main anticyclonic gyres of approximately 100 km diameter situated over the western and eastern Alboran Basins, respectively. Both main gyres are stable during summer, whereas in autumn and winter the flow regime especially of the Eastern Anticyclonic Gyre (EAG) fluctuates with seasonal hydrologic changes (Prieur and Sournia 1994; Vargas-Yáñez et al. 2002; Renault et al. 2012). The outflow of the Mediterranean Sea consists of the Levantine Intermediate Water close to the Iberian margin at around 200–600 m water depth and the Mediterranean Deep Water merging at the chokepoint of the Gibraltar Sill (Millot 1987). The shallow position of the MMF just east of the Cabo de Tres Forcas puts it under influence of the (modern) surface circulation of the intermittent and shifting EAG (Fink et al. 2013).

While Fink et al. (2013) identify the Bølling–Allerød interstadial and the Early Holocene as phases of accelerated coral growth linked to increased productivity and mound accumulation in the MMF, Stalder et al. (2015) include the early Younger Dryas based on abundant macro- and microfaunal evidence, high flux of labile carbon and sediment inferred accumulation rates.

Since the Palaeozoic ostracods (Crustacea) are a successful and diverse microfossil group that represent excellent palaeoenvironmental indicators characterizing most kinds of aquatic ecosystems (e.g. Smith and Horne 2002, Horne 2003). However, despite about 200 years of research their diversity is not yet fully documented (e.g., Rodriguez-Lazaro and Ruiz-Munoz 2012). In particular, studies on ostracods from cold-water coral ecosystems (CWC) are still scarce (e.g. Coles et al. 1996; Stalder et al. 2014; Sciuto and Rosso 2015), most with only a limited documentation of species based on SEM images. While research history of Recent (e.g. Müller 1894; Bonaduce et al. 1975; Montenegro et al. 1996; Sciuto 2014; Frezza and Di Bella 2015) and Pleistocene (e.g. Ruggieri 1984; Ciampo 2003; Hastrup and Thomsen 2005a, b; Faranda and Gliozzi 2008; Aiello et al. 2015) ostracod assemblages from Mediterranean subbasins is extensive, studies combining benthic Foraminifera and Ostracoda are scarce (Angue Minto’o et al. 2015; Stalder et al. 2015).

So far, only three investigations combining benthic Foraminifera and Ostracoda (and other fossil groups) associated to CWC have been carried out (Coles et al. 1996; Stalder et al. 2014, 2015). Stalder et al. (2015) recently demonstrated that the investigation of both benthic foraminifera and ostracods is giving palaeoecological insights in sediments from CWC ecosystems where the use of geochemical proxies may be limited due to the occurrence of hiatuses, highly fluctuating sedimentation rates and diagenetic overprint.

In the present study we present: (1) The taxonomy and species abundances of ostracods and their palaeoecological context in core TTR401G from the Melilla Mounds Field (Alboran Sea) spanning the last 13.1 ka documented by high resolution scanning electron images and morphological drawings. (2) The morphological variability in valves of Krithe praetexta along the core and its relationship to environmental forcing proposed in Stalder et al. (2015).

2 Materials and methods

Ostracoda are derived from the 560 cm long sediment core TTR17-401G recovered at 251 m water depth in the eastern Alboran Sea (35°19.273′N, 02°34.001′W; Fig. 1). Samples were collected directly onboard at intervals of 20 cm. Approximately 10 g of dry bulk sediments were sieved through three mesh sizes (63, 125 and 250 μm) and oven-dried at 40 °C. All ostracods were picked from the residues. Number of individuals is calculated from the sum of carapaces and the highest number of right versus left valves.

The determination of Ostracoda follows the comprehensive overview of Hartmann and Puri (1974). The latter is modified down to superfamily level according to Meisch (2000). The classification of the Trachyleberididae follows Liebau (1975). For a taxonomic remarks, synonymy lists, measurements (including length/height plots) and drawings of muscle scar patterns (Figs. 1–5 suppl.) kindly consult the electronic supplementary material (ESM).

Images of ostracod specimens were taken with a FEI Sirion XL30 FEG scanning electron microscope (SEM) and a Keyence digital light microscope at the University of Fribourg. The specimens were coated with a 40 nm thick gold layer. The material is stored at the Natural History Museum of Fribourg, Switzerland (ref. numbers NHMF 32931–32980).

The chronology and inferred sediment accumulation rates and hiatuses in the core are based on ¹⁴C ages of benthic Foraminifera (“Sediment”) and the planktonic Foraminifera assemblage shift (for details see Stalder et al. 2015). Discontinuities have been inferred from contradictive ¹⁴C ages of CWC at 12.9, 12.6 and 8.0 ka BP, respectively (Fig. 2). Benthic Foraminifera from core TTR17-401G are recorded and interpreted in detail in Stalder et al. (2015). Based on hierarchical clustering they are grouped in four distinct assemblages.

Fig. 2

Diversity, abundance and ostracod assemblages in core TTR17-401G

3 Results

Samples from core TTR-401G contain nine species (see Fig. 2 and below), four of which are only represented by adult specimens (for taxonomic remarks, drawings and measurements see supplementary material). The highest species richness of nine taxa and abundance of 18 adult and 27 juvenile specimens is reached at 420 cm below surface (BSF). Ostracod-barren samples are at 80, 120, 460, 500 and 520 cm BSF. For Paracypris polita and Cytherella robusta A-1 as well as A-2 stages are documented. Paracypris polita (Fig. 3) is the only consistently occurring and most abundant species in the entire core (Fig. 2).

Fig. 3

a Paracypris polita adult left valve 1164 × 484 µm (280 cm) (MHNF 32947), b Paracypris polita male left valve 1138 × 478 µm (420 cm) (MHNF 32934), c Paracypris polita male right valve 1154 × 453 µm (560 cm) (MHNF 32980), d Paracypris polita female right valve 1193 × 483 µm (420 cm) (MHNF 32931), e Paracypris polita A-1 instar left valve 996 × 417 µm (480 cm) (MHNF 32978), f Paracypris polita A-1 instar right valve 941 × 394 µm (420 cm), g Paracypris polita A-2 instar left valve 731 × 348 µm (420 cm) (MHNF 32945), h Paracypris polita A-2 instar right valve 766 × 344 µm (420 cm) (MHNF 32932), i Pterygocythereis sp. A-3? instar left valve 589 × 356 µm (420 cm) (MHNF 329357)

Based on abrupt diversity and abundance changes the core section is subdivided in three ostracod assemblages:

Ostracod assemblage 1 (OA1) ranges from 560 to 440 cm below BSF, shows low abundances (< 5 adult individuals) and contains mainly Paracypris polita, with only two rare accessory taxa (Krithe praetexta, Cytherella robusta).

At 420 cm BSF diversity and abundance suddenly increase to 9 species and 17 adult respectively 25 juvenile individuals marks the shift to OA2. Species richness (SR) in OA2 fluctuates between 2 and 6 taxa in the interval between 420 and 260 cm BSF, with adults and juveniles being continuously present. Paracypris polita (Fig. 3), Krithe praetexta (Figs. 6, 7), Cytherella robusta (Fig. 6) and Echinocythereis vidua (Fig. 5) represent the most common taxa. Accessory taxa comprise Macromckenziea ligustica (Fig. 4), Lanceostoma ensiforme (Fig. 4), Bythocythere bradyi (Fig. 5), Cytheropteron cf. hadriaticum (Fig. 4) and a juvenile of Pterygocythereis (Fig. 3), the three latter taxa only occur in OA2. Adults of Krithe praetexta in OA2 are about 7–15% longer than specimens from OA3 (Figs. 8, 1 suppl.), with a peak size near the middle of the OA2 interval. A similar pattern is displayed by the size distribution of A-1 Krithe instars in OAZ 2.

Fig. 4

a Cytheropteron cf. hadriaticum adult left valve 575 × 297 µm (420 cm) (MHNF 32940), b Cytheropteron cf. hadriaticum adult right valve 580 × 322 µm (260 cm) (MHNF 32951), c Macromckenziea ligustica adult left valve 1042 × 394 µm (420 cm) (MHNF 32933), d Macromckenziea ligustica adult right valve 989 × 406 µm (300 cm), e Lanceostoma ensiforme adult right valve 785 × 355 µm (260 cm) (MHNF 32950), f Lanceostoma ensiforme adult left valve 749 × 324 µm (260 cm)

Fig. 5

a Bythocythere bradyi adult right valve 619 × 341 µm (420 cm) (MHNF 32946), b Echinocythereis vidua adult right valve 831 × 448 µm (380 cm) (MHNF 32952), c Echinocythereis vidua adult left valve 792 × 464 µm (420 cm) (MHNF 32942), d Echinocythereis vidua A-1 instar right valve 708 × 408 µm (420 cm) (MHNF 32943), e Echinocythereis vidua A-1 instar left valve 673 × 413 µm (420 cm) (MHNF 32936)

Fig. 6

a Cytherella robusta adult right valve 877 × 544 µm (420 cm) (MHNF 32975), b Cytherella robusta A-1 instar right valve 732 × 485 µm (400 cm) (MHNF 32974), c Cytherella robusta A-1 instar right valve 615 × 412 µm (420 cm) (MHNF 32941), d Krithe praetexta stressed female right valve 670 × 336 µm (100 cm) (MHNF 32954), e Krithe praetexta stressed male left valve 679 × 326 µm (100 cm) (MHNF 32953), f Krithe praetexta stressed female left valve 666 × 370 µm (100 cm) (MHNF 32955), g Krithe praetexta male left valve 740 × 362 µm (280 cm) (MHNF 32949), h Krithe praetexta small normal male right valve 726 × 338 µm (280 cm) i Krithe praetexta A-1 instar left valve 573 × 326 µm (280 cm) (MHNF 32948)

Fig. 7

a Krithe praetexta female right valve 754 × 373 µm (300 cm) (MHNF 32969), b Krithe praetexta very large female left valve 804 × 419 µm (320 cm) (MHNF 32970), c Krithe praetexta female left valve 737 × 404 µm (420 cm) (MHNF 32944), d Krithe praetexta female right valve 729 × 375 µm (420 cm) (MHNF 32937), e Krithe praetexta small normal male left valve 726 × 354 µm (420 cm) (MHNF 32938), f Krithe praetexta A-1 instar left valve 576 × 340 µm (420 cm), g Krithe praetexta A-1 instar right valve 587 × 332 µm (420 cm) (MHNF 32939)

Fig. 8

Temporal and ecological subdivision of core TTR17-401G and corresponding valve length of Krithe praetexta. Benthic (BFA) and planktic Foraminifera assemblages, absolute dating, geochemistry and grain size according to Stalder et al. (2015) (MINC mineral carbon, BF benthic Foraminifera)

In the lower part of ostracod assemblage 3 between 240 and 80 cm BSF the SR never exceeds more than one taxon per sample. Towards the sediment surface from 60 cm BSF the SR in OA3 steadily increases from 0 to 4. Altogether OA3 features a slightly higher SR than OA1 (5 vs. 3 taxa), consisting of Paracypris polita, Krithe praetexta and juveniles of Echinocythereis vidua and Cytherella robusta.

4 Discussion

4.1 Wider palaeoenvironmental context

There is a general consensus that ostracods do not tolerate truly anoxic conditions, though there are assemblages seemingly adapted to reduced levels of bottom oxygenation (Dingle 1995). This observation coincides with the higher species richness and abundances during BFA2/OA2 (dominance of benthic epifaunal taxa) and OA2, respectively and the inferred increased bottom water ventilation (Stalder et al. 2015; Fig. 8).

Since the genus Krithe has been attributed to the endobenthos (McKenzie et al. 1989; Coles et al. 1994; Majoran and Agrenius 1995), its abundance in BFA2/OA2 also indicates oxygenation of the uppermost sediment layer. This is born out by the more abundant occurrence of larger-sized Krithe praetexta specimens compared to OA1 and OA3, indicating environmentally stressed specimens not reaching their optimum size (Figs. 8, 5 suppl.). Occurrence peaks of the genus Echinocythereis in so-called “cold-assemblages” has been linked to a mixed water column and abundance of nutrients (Bassetti et al. 2010). Downwelling of more dense surface water in BFA1 and BFA2 probably contributed to the higher levels of bottom water oxygenation and nutrient supply.

Increases of ostracod abundance and species richness as well as an assemblage change comparable to the Melilla CWC mound have been reported in the Younger Dryas of the Mediterranean from non-CWC related settings. Angue Minto’o et al. (2015) report a shift from a Paracypris polita dominated assemblage during the last glacial period to a diverse assemblage in the Younger Dryas with higher percentages of Krithe spp. and Macrocyprididae comparable to the development in OA2. Absence of ostracods during the Bølling–Allerød interstadial has been linked to increased freshwater influx (Ciampo 2003), as in our samples in OA1.

In a core from the deep southeastern Adriatic Basin (at 1207 mbsl) however, a maximal species richness (17 taxa) was recorded for the Bølling–Allerød interstadial that decreased to 12 and 10 species in the Younger Dryas and earliest Holocene, respectively (Breman 1975). This discrepancy is certainly due to alterations of water circulation patterns (thus benthic conditions) in different Mediterranean subbasins in the last glacial period and the Holocene.

During the younger Dryas peaks of allochthonous Ostracoda have been reported (El Hmaidi et al. 2010; Angue Minto’o et al. 2015) from the Mediterranean. The only species from core 401G that may be considered as allochthonous is Lanceostoma ensiforme, a species of the predominantly phytal Paradoxostomatidae generally recorded from rather shallow depths (Whatley and Wall 1975; Hull 1999). However, the presence of Paradoxostomatidae in CWCs has been interpreted to represent an in situ depth range extension of shallow-water taxa due to the availability of abundant nutriments (Coles et al. 1996; Sciuto and Rosso 2015). All other ostracod species occur in recent water depth ranges including the water depths measured and deduced for core 401G and are thus considered to represent autochthonous species.

4.2 Melilla mound context (core TTR-401G)

Stalder et al. (2015) group the benthic Foraminifera of core TTR-401G in four assemblages (BFA1-4 in Fig. 8). The near absence of ostracods in BFA1/OA2 is due to the instable and insufficiently ventilated bottom water conditions as inferred from the benthic Foraminifera and the geochemical data in Stalder et al. (2015) have been linked to continental and oceanic freshwater inputs, inhibiting the development of a suitable benthic environment favourable for ostracod proliferation.

BFA2 conforms to OA2 and is characterized by high abundances of epifaunal benthic Foraminifera taxa (Cibicides spp., Cibicidoides pachyderma) and a low plankton/benthos foraminiferal-ratio (P/B-ratio). Discanomalina coronata as taxon representing well-ventilated sea floors (Margreth et al. 2009) is nearly exclusively limited to BFA2/OA2.

Ostracod assemblage 1 and 3 are similar in that they show low diversity (0–2 species per sample) and abundance (adult and juveniles each below 5 specimens per sample), with the main faunal components being Paracypris polita and environmentally stressed (see Sect. 4.1) Krithe praetetxta. While the lower part of BFA1 conforms to OA1, the detailed subdivision of interval 240–0 cm in a recurring BFA1 and BFA3-4 cannot be reproduced for OA3 (Fig. 8), probably due to the limited sample size and associated few ostracod specimens.

Based on grain size data and lithology provided in Stalder et al. (2015) peaks in ostracod abundance and species richness correlate roughly to a general decrease of the smaller than 63 µm-fraction in interval 420–260 cm as well as to maxima in intermediate grain sizes (63–250 µm) in samples 380 and 420 cm (since the > 250 µm fraction was not subdivided further it remains difficult to interpret). In general, ostracods are more diverse and abundant on sandy than on clayey mud substrates.

The correlation of ostracod abundance and diversity in relation to sediment grain size has been investigated in the past, however without definite conclusions. Kilenyi (1969) measured grain sizes conducive for high ostracod abundance and diversity in the Thames estuary to generally lie between 100 and 250 µm. Sediments strongly adverse to ostracod proliferation have been associated with “fluid mud” (thixotrope mud-water mixture) and more than 10% of the 250–500 µm fraction. Since these results were obtained in a high-energy environment unanswered question concerning effects of transport, substrate mobility and sorting remain (e.g. Kilenyi 1969, 1971). Krutak (1971, 1972) reports maximum abundance and diversity from poorly sorted medium and fine sands (125–500 µm) of a tidal lagoon in the Gulf of Mexico.

Comparing substrate preferences of recent Mediterranean taxa similar to our species in water depths and lower energy settings comparable to core 401G (e.g. Adriatic Sea; Bonaduce et al. 1975) is not straightforward, but also seems to indicate a general tendency towards silty and sandy mud.

The interpretation of geochemical proxies sensu Stalder et al. (2015) in relation to the OA subdivision remains more ambiguous, with higher ratios of mineral carbon generally correlating with higher ostracod diversity and abundance. Other geochemical indicators like δ¹³C_org however do not mirror ostracod assemblage development (Fig. 8).

4.3 Comparison to other CWC mound ostracod assemblages

The (sub)recent dead and live ostracod taxa recorded from the deeper (505–790 vs. 252 m) extant Santa Maria di Leuca CWC mound offshore southern Apulia shows a nearly entirely different species composition (Sciuto and Rosso 2015) compared to uppermost subrecent samples (≥ 600 a BP) in core TTR-401G with two living and 40 subfossil taxa. Accordingly the record features a higher percentage of cold-water and/or deeper-living taxa. On species level only Lanceostoma ensiforme (listed as Paradoxostoma simile in Sciuto and Rosso 2015), Krithe praetexta and Cytheropteron hadriaticum occur in both CWC (with two identical species in the respective surface sample), whereas 7 genera are conform. Interesting is the absence of Paracypris in the Santa Maria di Leuca CWC mound, which is probably due to the greater water depth of the latter.

The much higher overall diversity of 42 versus 4 recent/subfossil ostracod taxa in core TTR-401G may be related to the larger sample volume (300 ccm vs. 10 g) or to the larger spectrum of analysed CWC facies (6 vs. 1). Highest diversities in the Santa Maria di Leuca CWC mound are developed in the coral framework (22 species) and Foraminifera marl (25 species) facies, with the latter showing a high percentage of exclusive taxa. The lowest diversity is recorded in the coral rubble facies (4 species). This mirrors the stratigraphical development in core TTR-401G core, where the occurrence of the benthic foraminifer Discanomalina coronata as indicator for living CWC frameworks (Margreth et al. 2009) is nearly exclusively limited BFA2/OA2, hinting at in situ CWC growth in the lower Younger Dryas, whereas low abundance and diversity in OA1 and OA3 can be attributed to unfavourable bottom conditions and as well as a shift from a coral framework to coral rubble setting.

Coles et al. (1996) record typical upper bathyal benthic foraminifer and ostracod assemblages from a comparable time-slice (Bølling–Allerød to Recent) of CWC mounds in the Porcupine Basin offshore southwestern Ireland with sample depth ranging from 610 to 750 m. On-mound diversity is much higher than off-mound speculating on the importance of hard substrate for diversity, comparable to the results of the Santa Maria di Leuca CWC mound (see above). Being of deeper northeastern Atlantic provenance, the difference at species level between the Porcupine Seabight and the Melilla Mound Field is not surprising. Only Krithe praetexta is recorded from both sites, whereas Paracypris polita is interpreted as allochthonous. There are 5 conform autochthonous genera.

5 Conclusions

The 560 cm long sediment core TTR17-401G from the Melilla cold-water coral mound field spanning the last 13 ka in the eastern Alboran Sea yielded nine ostracod species, consistently dominated by Paracypris polita. Based on abrupt diversity and abundance changes the core is subdivided in three distinct ostracod assemblages, correlating to the Bølling–Allerød interstadial, the early Younger Dryas and the Holocene, respectively. The highest species richness and abundance is achieved in ostracod assemblage 2 (OA2) that thrived during the early Younger Dryas, indicating prevailing well-oxygenated and nutrient-rich bottom conditions. The distribution of distinctly larger specimens of Krithe praetexta in OA2 suggests that ecological conditions were conducive for optimal growth of this species. Environmentally stressed specimens from OA3 and OA1 also show comparatively shorter lateral outlines. Higher ostracod abundances and species richness generally correlate with a decrease of the silt/clay- and an increase of fine-medium sand-fraction. These results corroborate the interpretation of geochemical and faunal proxies of core TTR17-401G elaborated in a previous study.

The taxonomical analysis of the ostracod taxa reveals well know and expected species from the geographical position and the intermediate water depth, with the exception of Bythocythere bradyi being for the first time recorded in the Mediterranean. The higher ostracod abundance and species richness in OA2 in the early Younger Dryas and the subsequent depletion in OA3 during the Holocene mirrors ostracod assemblage shifts reported elsewhere in the Mediterranean.
